铜芯聚氯乙烯绝缘聚氯乙烯护套编织屏蔽控制软电缆 KVVRP 型
— 技术参数
参考标准:GB/T9330.2-2008
额定电压:U0/U 为450/750V
额定温度:70℃
— 产品应用
本产品适用于交流额定电压U0/U 为450/750V 及以下控制,监控回路及保护线路等要求屏蔽场所使用的聚氯乙烯绝缘和聚氯
乙烯护套控制软电缆。
— 使用特性
1. 电缆导体允许长期工作温度应不超过70℃
2. 电缆敷设温度应不低于0℃
3. 敷设时电缆允许弯曲半径应不小于电缆外径的6 倍
4. 护套材料为优质聚氯乙烯,抗老化,耐磨损,防水,防油,防化学腐蚀,无毒等特性
KVVRP 型450/750V 铜芯聚氯乙烯绝缘聚氯乙烯护套编织屏蔽控制软电缆的综合数据
|
芯线X 标称 截面(mm2)
|
导体结构(NO.mm)
|
绝缘厚度 规定值(mm)
|
屏蔽单线标称直径(mm)
|
护套厚度 规定值(mm)
|
多支绞合导体电缆外形尺寸(mm)
|
20℃时导体 电阻 最大值(Ω/KM)
|
70℃时绝缘 电阻 最小值(MΩ/KM)
|
|
|
|
|
|
下限
|
上限
|
|
|
KVVRP2X0.5
|
16/0.20
|
0.6
|
0.15
|
1.2
|
7.4
|
9.3
|
39
|
0.013
|
KVVRP2X0.75
|
24/0.20
|
0.6
|
0.15
|
1.2
|
7.7
|
9.7
|
26
|
0.011
|
KVVRP2X1.0
|
32/0.20
|
0.6
|
0.15
|
1.2
|
8
|
10
|
19.5
|
0.01
|
KVVRP2X1.5
|
48/0.20
|
0.7
|
0.15
|
1.2
|
8.9
|
11.1
|
13.3
|
0.01
|
KVVRP2X2.5
|
49/0.25
|
0.8
|
2
|
1.5
|
10.1
|
12.6
|
7.98
|
0.009
|
KVVRP3X0.5
|
16/0.20
|
0.6
|
0.15
|
1.2
|
7.8
|
9.7
|
39
|
0.013
|
KVVRP3X0.75
|
24/0.20
|
0.6
|
0.15
|
1.2
|
8.1
|
10.1
|
26
|
0.011
|
KVVRP3X1.0
|
32/0.20
|
0.6
|
0.15
|
1.2
|
8.4
|
10.5
|
19.5
|
0.01
|
KVVRP3X1.5
|
48/0.20
|
0.7
|
0.15
|
1.2
|
9.3
|
11.6
|
13.3
|
0.01
|
KVVRP3X2.5
|
49/0.25
|
0.8
|
2
|
2.5
|
10.7
|
13.2
|
7.98
|
0.009
|
KVVRP4X0.5
|
16/0.20
|
0.6
|
0.15
|
1.2
|
8.3
|
10.4
|
39
|
0.013
|
KVVRP4X0.75
|
24/0.20
|
0.6
|
0.15
|
1.2
|
8.6
|
10.8
|
26
|
0.011
|
KVVRP4X1.0
|
32/0.20
|
0.6
|
0.15
|
1.2
|
9
|
11.2
|
19.5
|
0.01
|
KVVRP4X1.5
|
48/0.20
|
0.7
|
0.15
|
1.2
|
10
|
12.5
|
13.3
|
0.01
|
KVVRP4X2.5
|
49/0.25
|
0.8
|
0.2
|
1.5
|
11.5
|
14.3
|
7.98
|
0.009
|
KVVRP5X0.5
|
16/0.20
|
0.6
|
0.15
|
1.2
|
8.9
|
11.1
|
39
|
0.013
|
KVVRP5X0.75
|
24/0.20
|
0.6
|
0.15
|
1.2
|
9.3
|
11.6
|
26
|
0.011
|
KVVRP5X1.0
|
32/0.20
|
0.6
|
0.15
|
1.2
|
9.7
|
12
|
19.5
|
0.01
|
KVVRP5X1.5
|
48/0.20
|
0.7
|
0.15
|
1.2
|
10.8
|
13.4
|
13.3
|
0.01
|
KVVRP5X2.5
|
49/0.25
|
0.8
|
0.2
|
1.5
|
13.3
|
16.5
|
7.98
|
0.009
|
KVVRP7X0.5
|
16/0.20
|
0.6
|
0.15
|
1.2
|
9.5
|
11.8
|
39
|
0.013
|
KVVRP7X0.75
|
24/0.20
|
0.6
|
0.15
|
1.2
|
9.9
|
12.4
|
26
|
0.011
|
KVVRP7X1.0
|
32/0.20
|
0.6
|
0.15
|
1.2
|
10.4
|
12.9
|
19.5
|
0.01
|
KVVRP7X1.5
|
48/0.20
|
0.7
|
0.15
|
1.2
|
12.2
|
15.1
|
13.3
|
0.01
|
KVVRP7X2.5
|
49/0.25
|
0.8
|
0.2
|
2.5
|
14.3
|
17.7
|
7.98
|
0.009
|
KVVRP8X0.5
|
16/0.20
|
0.6
|
0.15
|
1.2
|
10.4
|
13
|
39
|
0.013
|
KVVRP8X0.75
|
24/0.20
|
0.6
|
0.15
|
1.2
|
10.9
|
13.6
|
26
|
0.011
|
KVVRP8X1.0
|
32/0.20
|
0.6
|
0.15
|
1.5
|
11.4
|
14.2
|
19.5
|
0.01
|
KVVRP8X1.5
|
48/0.20
|
0.7
|
0.2
|
1.5
|
13.7
|
16.9
|
13.3
|
0.01
|
KVVRP8X2.5
|
49/0.25
|
0.8
|
0.2
|
1.5
|
15.9
|
19.5
|
7.98
|
0.009
|
KVVRP10X0.5
|
16/0.20
|
0.6
|
0.15
|
1.5
|
11.6
|
14.3
|
39
|
0.013
|
KVVRP10X0.75
|
24/0.20
|
0.6
|
0.2
|
1.5
|
12.7
|
15.7
|
26
|
0.011
|
KVVRP10X1.0
|
32/0.20
|
0.6
|
0.2
|
1.5
|
13.5
|
16.7
|
19.5
|
0.01
|
KVVRP10X1.5
|
48/0.20
|
0.7
|
0.2
|
1.5
|
15.3
|
18.8
|
13.3
|
0.01
|
KVVRP10X2.5
|
49/0.25
|
0.8
|
0.2
|
1.5
|
17.7
|
21.8
|
7.98
|
0.009
|
KVVRP12X0.5
|
16/0.20
|
0.6
|
0.15
|
1.5
|
12.5
|
15.4
|
39
|
0.013
|
KVVRP12X0.75
|
24/0.20
|
0.6
|
0.2
|
1.5
|
13.3
|
16.4
|
26
|
0.011
|
KVVRP12X1.0
|
32/0.20
|
0.6
|
0.2
|
1.5
|
13.9
|
17.2
|
19.5
|
0.01
|
KVVRP12X1.5
|
48/0.20
|
0.7
|
0.2
|
1.5
|
15.7
|
19.3
|
13.3
|
0.01
|
KVVRP12X2.5
|
49/0.25
|
0.8
|
0.2
|
1.7
|
18.7
|
22.9
|
7.98
|
0.009
|
KVVRP14X0.5
|
16/0.20
|
0.6
|
0.2
|
1.5
|
13.2
|
16.3
|
39
|
0.013
|
KVVRP14X0.75
|
24/0.20
|
0.6
|
0.2
|
1.5
|
13.9
|
17.1
|
26
|
0.011
|
KVVRP14X1.0
|
32/0.20
|
0.6
|
0.2
|
1.5
|
14.5
|
17.9
|
19.5
|
0.01
|
KVVRP14X1.5
|
48/0.20
|
0.7
|
0.2
|
1.5
|
16.4
|
20.2
|
13.3
|
0.01
|
KVVRP14X2.5
|
49/0.25
|
0.8
|
0.2
|
1.7
|
19.5
|
24
|
7.98
|
0.009
|
KVVRP16X0.5
|
16/0.20
|
0.6
|
0.2
|
1.5
|
13.8
|
17.1
|
39
|
0.013
|
KVVRP16X0.75
|
24/0.20
|
0.6
|
0.2
|
1.5
|
14.5
|
17.9
|
26
|
0.011
|
KVVRP16X1.0
|
32/0.20
|
0.6
|
0.2
|
1.5
|
15.2
|
18.7
|
19.5
|
0.01
|
KVVRP16X1.5
|
48/0.20
|
0.7
|
0.2
|
1.5
|
17.2
|
21.1
|
13.3
|
0.01
|
KVVRP16X2.5
|
49/0.25
|
0.8
|
0.2
|
1.7
|
20.5
|
25.2
|
7.98
|
0.009
|
KVVRP19X0.5
|
16/0.20
|
0.6
|
0.2
|
1.5
|
14.4
|
17.8
|
39
|
0.013
|
KVVRP19X0.75
|
24/0.20
|
0.6
|
0.2
|
1.5
|
15.2
|
18.7
|
26
|
0.011
|
KVVRP19X1.0
|
32/0.20
|
0.6
|
0.2
|
1.5
|
15.9
|
19.5
|
19.5
|
0.01
|
KVVRP19X1.5
|
48/0.20
|
0.7
|
0.2
|
1.7
|
18.4
|
22.6
|
13.3
|
0.01
|
KVVRP19X2.5
|
49/0.25
|
0.8
|
0.2
|
1.7
|
21.5
|
26.4
|
7.98
|
0.009
|
KVVRP24X0.5
|
16/0.20
|
0.6
|
0.2
|
1.5
|
16.5
|
20.3
|
39
|
0.013
|
KVVRP24X0.75
|
24/0.20
|
0.6
|
0.2
|
1.5
|
17.4
|
21.3
|
26
|
0.011
|
KVVRP24X1.0
|
32/0.20
|
0.6
|
0.2
|
1.7
|
18.6
|
22.9
|
19.5
|
0.01
|
KVVRP24X1.5
|
48/0.20
|
0.7
|
0.2
|
1.7
|
21.2
|
26
|
13.3
|
0.01
|
KVVRP24X2.5
|
49/0.25
|
0.8
|
0.2
|
1.7
|
25.2
|
30.8
|
7.98
|
0.009
|
KVVRP27X0.5
|
16/0.20
|
0.6
|
0.2
|
1.5
|
16.8
|
20.7
|
39
|
0.013
|
KVVRP27X0.75
|
24/0.20
|
0.6
|
0.2
|
1.5
|
17.7
|
21.7
|
26
|
0.011
|
KVVRP27X1.0
|
32/0.20
|
0.6
|
0.2
|
1.7
|
19
|
23.3
|
19.5
|
0.01
|
KVVRP27X1.5
|
48/0.20
|
0.7
|
0.2
|
1.7
|
21.6
|
26.5
|
13.3
|
0.01
|
KVVRP27X2.5
|
49/0.25
|
0.8
|
0.2
|
1.7
|
25.7
|
31.4
|
7.98
|
0.009
|
KVVRP30X0.5
|
16/0.20
|
0.6
|
0.2
|
1.5
|
17.3
|
21.3
|
39
|
0.013
|
KVVRP30X0.75
|
24/0.20
|
0.6
|
0.2
|
1.7
|
18.7
|
22.9
|
26
|
0.011
|
KVVRP30X1.0
|
32/0.20
|
0.6
|
0.2
|
1.7
|
19.6
|
24
|
19.5
|
0.01
|
KVVRP30X1.5
|
48/0.20
|
0.7
|
0.25
|
1.7
|
22.3
|
27.4
|
13.3
|
0.01
|
KVVRP30X2.5
|
49/0.25
|
0.8
|
0.25
|
1.7
|
26.6
|
32.5
|
7.98
|
0.009
|
KVVRP37X0.5
|
16/0.20
|
0.6
|
0.2
|
1.7
|
18.9
|
23.3
|
39
|
0.013
|
KVVRP37X0.75
|
24/0.20
|
0.6
|
0.2
|
1.7
|
20
|
24.5
|
26
|
0.011
|
KVVRP37X1.0
|
32/0.20
|
0.6
|
0.2
|
1.7
|
21
|
25.7
|
19.5
|
0.01
|
KVVRP37X1.5
|
48/0.20
|
0.7
|
0.25
|
1.7
|
24.2
|
29.6
|
13.3
|
0.01
|
KVVRP37X2.5
|
49/0.25
|
0.8
|
0.25
|
2
|
29.2
|
35.6
|
7.98
|
0.009
|
KVVRP44X0.5
|
16/0.20
|
0.6
|
0.2
|
1.7
|
21
|
25.8
|
39
|
0.013
|
KVVRP44X0.75
|
24/0.20
|
0.6
|
0.25
|
1.7
|
22.2
|
27.1
|
26
|
0.011
|
KVVRP44X1.0
|
32/0.20
|
0.6
|
0.25
|
1.7
|
23.6
|
28.8
|
19.5
|
0.01
|
KVVRP44X1.5
|
48/0.20
|
0.7
|
0.25
|
1.7
|
27.6
|
33.7
|
13.3
|
0.01
|
KVVRP44X2.5
|
49/0.25
|
0.8
|
0.3
|
2
|
33
|
40.2
|
7.98
|
0.009
|
KVVRP48X0.5
|
16/0.20
|
0.6
|
0.2
|
1.7
|
21.3
|
26.1
|
39
|
0.013
|
KVVRP48X0.75
|
24/0.20
|
0.6
|
0.25
|
1.7
|
22.5
|
27.5
|
26
|
0.011
|
KVVRP48X1.0
|
32/0.20
|
0.6
|
0.25
|
1.7
|
23.9
|
29.3
|
19.5
|
0.01
|
KVVRP48X1.5
|
48/0.20
|
0.7
|
0.25
|
1.7
|
28
|
34.2
|
13.3
|
0.01
|
KVVRP48X2.5
|
49/0.25
|
0.8
|
0.3
|
2
|
33.5
|
40.8
|
7.98
|
0.009
|
KVVRP52X0.5
|
16/0.20
|
0.6
|
0.2
|
1.7
|
21.9
|
26.8
|
39
|
0.013
|
KVVRP52X0.75
|
24/0.20
|
0.6
|
0.25
|
1.7
|
23.1
|
28.2
|
26
|
0.011
|
KVVRP52X1.0
|
32/0.20
|
0.6
|
0.25
|
1.7
|
24.5
|
30
|
19.5
|
0.01
|
KVVRP61X0.5
|
16/0.20
|
0.6
|
0.25
|
1.7
|
23.1
|
28.2
|
39
|
0.013
|
KVVRP61X0.75
|
24/0.20
|
0.6
|
0.25
|
1.7
|
24.6
|
30.1
|
26
|
0.011
|
KVVRP61X1.0
|
32/0.20
|
0.6
|
0.25
|
1.7
|
25.9
|
31.7
|
19.5
|
0.01
|
