铜芯聚氯乙烯绝缘聚氯乙烯护套钢带铠装控制电缆 KVV22 型
— 技术参数
参考标准：GB/T9330.2-2008
额定电压：U0/U 为450/750V
额定温度：70℃
— 产品应用
本产品适用于交流额定电压U0/U 为450/750V 及以下控制，监控回路及保护线路等要求承受较大机械外力场合的聚氯乙烯
绝缘聚氯乙烯护套钢带控制电缆。
— 使用特性
1. 电缆导体允许长期工作温度应不超过70℃
2. 电缆敷设温度应不低于0℃
3. 敷设时电缆允许弯曲半径应不小于电缆外径的12 倍
4. 护套材料为优质聚氯乙烯，抗老化，耐磨损，防水，防油，防化学腐蚀，无毒等特性
KVV22 型450/750V 铜芯聚氯乙烯绝缘聚氯乙烯护套钢带铠装控制电缆的综合数据
|
芯线X 标称 截面（mm2）
|
导体结构(NO.mm）
|
绝缘厚度 规定值（mm）
|
钢带层数×厚度（mm）
|
护套厚度 规定值（mm）
|
电缆外形尺寸（mm）
|
20℃时导体 电阻 最大值(Ω/KM)
|
70℃时绝缘 电阻 最小值 (MΩ/KM)
|
|
|
|
|
|
|
下限
|
上限
|
|
|
|
KVV22 4X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.5
|
12
|
14.4
|
12.1
|
0.011
|
|
KVV22 4X2.5
|
1/1.78
|
0.8
|
2X0.2
|
1.5
|
13.4
|
16.1
|
7.41
|
0.01
|
|
KVV22 4X4
|
1/2.25
|
0.8
|
2X0.2
|
1.5
|
14.4
|
17.4
|
4.61
|
0.0085
|
|
KVV22 4X6
|
1/2.76
|
0.8
|
2X0.2
|
1.5
|
15.6
|
18.8
|
3.08
|
0.007
|
|
KVV22 4X10
|
7/1.33
|
1
|
2X0.2
|
1.5
|
19.4
|
23.5
|
1.83
|
0.0065
|
|
KVV22 5X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.5
|
12.7
|
15.3
|
12.1
|
0.011
|
|
KVV22 5X2.5
|
1/1.78
|
0.8
|
2X0.2
|
1.7
|
14.3
|
17.2
|
7.41
|
0.01
|
|
KVV22 5X4
|
1/2.25
|
0.8
|
2X0.2
|
1.5
|
15.4
|
18.6
|
4.61
|
0.0085
|
|
KVV22 5X6
|
1/2.76
|
0.8
|
2X0.2
|
1.5
|
16.7
|
20.2
|
3.08
|
0.007
|
|
KVV22 5X10
|
7/1.33
|
1
|
2X0.2
|
1.7
|
21
|
25.4
|
1.83
|
0.0065
|
|
KVV22 7X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.5
|
11.8
|
14.2
|
24.5
|
0.012
|
|
KVV22 7X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.5
|
12.2
|
14.7
|
18.1
|
0.011
|
|
KVV22 7X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.5
|
13.5
|
16.3
|
12.1
|
0.011
|
|
KVV22 7X2.5
|
1/1.78
|
0.8
|
2X0.2
|
1.5
|
15.2
|
18.4
|
7.41
|
0.01
|
|
KVV22 7X4
|
1/2.25
|
0.8
|
2X0.2)
|
1.5
|
16.5
|
20
|
4.61
|
0.0085
|
|
KVV22 7X6
|
1/2.76
|
0.8
|
2X0.2
|
1.7
|
18
|
21.7
|
3.08
|
0.007
|
|
KVV22 7X10
|
7/1.33
|
1
|
2X0.2
|
1.7
|
22.7
|
27.4
|
1.83
|
0.0065
|
|
KVV22 8X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.5
|
12.7
|
15.3
|
24.5
|
0.012
|
|
KVV22 8X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.5
|
13.2
|
15.9
|
18.1
|
0.011
|
|
KVV22 8X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.5
|
14.7
|
17.7
|
12.1
|
0.011
|
|
KVV22 8X2.5
|
1/1.78
|
0.8
|
2X0.2
|
1.5
|
16.7
|
20.1
|
7.41
|
0.01
|
|
KVV22 8X4.0
|
1/2.25
|
0.8
|
2X0.2
|
1.7
|
18.2
|
21.9
|
4.61
|
0.0085
|
|
KVV22 8X6.0
|
1/2.76
|
0.8
|
2X0.2
|
1.7
|
20.2
|
24.4
|
3.08
|
0.007
|
|
KVV22 8X10.0
|
7/1.33
|
1
|
2X0.2
|
1.7
|
25.2
|
30.4
|
1.83
|
0.0065
|
|
KVV22 10X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.5
|
13.8
|
16.7
|
24.5
|
0.012
|
|
KVV22 10X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.5
|
14.4
|
17.4
|
18.1
|
0.011
|
|
KVV22 10X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.5
|
16.1
|
19.5
|
12.1
|
0.011
|
|
KVV22 10X2.5
|
1/1.78
|
0.8
|
2X0.2
|
1.7
|
18.8
|
22.7
|
7.41
|
0.01
|
|
KVV22 10X4
|
1/2.25
|
0.8
|
2X0.2)
|
1.7
|
20.5
|
24.8
|
4.61
|
0.0085
|
|
KVV22 10X6
|
1/2.76
|
0.8
|
2X0.2
|
1.7
|
22.5
|
27.1
|
3.08
|
0.007
|
|
KVV22 10X10
|
7/1.33
|
1
|
2X0.2
|
2
|
29.2
|
35.3
|
1.83
|
0.0065
|
|
KVV22 12X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.5
|
14.1
|
17.1
|
24.5
|
0.012
|
|
KVV22 12X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.5
|
14.8
|
17.8
|
18.1
|
0.011
|
|
KVV22 12X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.5
|
16.6
|
20
|
12.1
|
0.011
|
|
KVV22 12X2.5
|
1/1.78
|
0.8
|
2X0.2
|
1.7
|
19.3
|
23.4
|
7.41
|
0.01
|
|
KVV22 12X4
|
1/2.25
|
0.8
|
2X0.2
|
1.7
|
21.1
|
25.5
|
4.61
|
0.0085
|
|
KVV22 12X6
|
1/2.76
|
0.8
|
2X0.2
|
1.7
|
23.1
|
27.9
|
3.08
|
0.007
|
|
KVV22 14X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.5
|
14.7
|
17.7
|
24.5
|
0.012
|
|
KVV22 14X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.5
|
15.3
|
18.5
|
18.1
|
0.011
|
|
KVV22 14X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.7
|
17.2
|
20.8
|
12.1
|
0.011
|
|
KVV22 14X2.5
|
1/1.78
|
0.8
|
2X0.2
|
1.7
|
20.1
|
24.3
|
7.41
|
0.01
|
|
KVV22 14X4
|
1/2.25
|
0.8
|
2X0.2
|
1.7
|
22
|
26.6
|
4.61
|
0.0085
|
|
KVV22 14X6
|
1/2.46
|
0.8
|
2X0.2
|
1.7
|
24.2
|
29.2
|
3.08
|
0.007
|
|
KVV22 16X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.5
|
15.3
|
18.5
|
24.5
|
0.012
|
|
KVV22 16X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.5
|
16
|
19.3
|
18.1
|
0.011
|
|
KVV22 16X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.7
|
18
|
21.7
|
12.1
|
0.011
|
|
KVV22 16X2.5
|
1/1.78
|
0.8
|
2X0.2
|
1.7
|
21.1
|
25.5
|
7.41
|
0.01
|
|
KVV22 19X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.5
|
15.9
|
19.2
|
24.5
|
0.012
|
|
KVV22 19X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.7
|
16.6
|
20.1
|
18.1
|
0.011
|
|
KVV22 19X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.7
|
19.2
|
23.1
|
12.1
|
0.011
|
|
KVV22 19X2.5
|
1/1.78
|
0.8
|
2X0.2
|
1.7
|
22
|
26.6
|
7.41
|
0.01
|
|
KVV22 24X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.7
|
18
|
21.7
|
24.5
|
0.012
|
|
KVV22 24X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.7
|
19.2
|
23.2
|
18.1
|
0.011
|
|
KVV22 24X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.7
|
21.8
|
26.3
|
12.1
|
0.011
|
|
KVV22 24X2.5
|
1/1.78
|
0.8
|
2X0.2
|
1.7
|
25.6
|
31
|
7.41
|
0.01
|
|
KVV22 27X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.7
|
18.7
|
22.5
|
24.5
|
0.012
|
|
KVV22 27X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.7
|
19.2
|
23.2
|
18.1
|
0.011
|
|
KVV22 27X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.7
|
22.2
|
26.8
|
12.1
|
0.011
|
|
KVV22 27X2.5
|
1/1.78
|
0.8
|
2X0.2
|
1.7
|
26.1
|
31.6
|
7.41
|
0.01
|
|
KVV22 30X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.7
|
19.2
|
23.2
|
24.5
|
0.012
|
|
KVV22 30X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.7
|
20.1
|
24.3
|
18.1
|
0.011
|
|
KVV22 30X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.7
|
22.9
|
27.6
|
12.1
|
0.011
|
|
KVV22 30X2.5
|
1/1.78
|
0.8
|
2X0.2
|
1.7
|
27
|
32.6
|
7.41
|
0.01
|
|
KVV22 37X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.7
|
20.4
|
24.7
|
24.5
|
0.012
|
|
KVV22 37X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.7
|
21.4
|
25.9
|
18.1
|
0.011
|
|
KVV22 37X1.5
|
1/1.38
|
0.7
|
2X0.2
|
1.7
|
24.4
|
29.5
|
12.1
|
0.011
|
|
KVV22 37X2.5
|
1/1.78
|
0.8
|
2X0.5
|
2
|
29.4
|
35.6
|
7.41
|
0.01
|
|
KVV22 44X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.7
|
22.5
|
27.1
|
24.5
|
0.012
|
|
KVV22 44X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.7
|
23.6
|
28.5
|
18.1
|
0.011
|
|
KVV22 44X1.5
|
1/1.38
|
0.7
|
2X0.2
|
2
|
28
|
33.9
|
12.1
|
0.011
|
|
KVV22 44X2.5
|
1/1.78
|
0.8
|
2X0.5
|
2.2
|
33
|
39.9
|
7.41
|
0.01
|
|
KVV22 48X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.7
|
22.8
|
27.5
|
24.5
|
0.012
|
|
KVV22 48X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.7
|
24
|
28.9
|
18.1
|
0.011
|
|
KVV22 48X1.5
|
1/1.38
|
0.7
|
2X0.5
|
2
|
28.4
|
34.4
|
12.1
|
0.011
|
|
KVV22 48X2.5
|
1/1.78
|
0.8
|
2X0.5
|
2.2
|
33.5
|
40.5
|
7.41
|
0.01
|
|
KVV22 52X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.7
|
23.3
|
28.2
|
24.5
|
0.012
|
|
KVV22 52X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.7
|
24.5
|
29.6
|
18.1
|
0.011
|
|
KVV22 52X1.5
|
1/1.38
|
0.7
|
2X0.5
|
2
|
29.1
|
35.2
|
12.1
|
0.011
|
|
KVV22 52X2.5
|
1/1.78
|
0.8
|
2X0.5
|
2.2
|
35.5
|
42.9
|
7.41
|
0.01
|
|
KVV22 61X0.75
|
1/0.97
|
0.6
|
2X0.2
|
1.7
|
24.5
|
29.6
|
24.5
|
0.012
|
|
KVV22 61X1.0
|
1/1.13
|
0.6
|
2X0.2
|
1.7
|
26.2
|
31.7
|
18.1
|
0.011
|
|
KVV22 61X1.5
|
1/1.38
|
0.7
|
2X0.5
|
2
|
30.7
|
37.1
|
12.1
|
0.011
|
|
KVV22 61X2.5
|
1/1.78
|
0.8
|
2X0.5
|
2.2
|
37.4
|
45.2
|
7.41
|
0.011
|
|
